In-Line Centrifugal Fan, Size 100A
CK100A (SWEDEN)
Availability: In Stock
Brand: Ostberg
Model: CK100A
Max. Airflow: 223 cmh
Duct Size: 100 mm
Power: 41 watts
Voltage: 230V-50/60H
Made in Sweden
Weight : 6.5kg
From SGD 300.00
Share:
| CK 100 A1 aut tp 7000030 | ||
|---|---|---|
| Parameter | Value | Unit |
| Voltage | 230 | V |
| Phase | 1 | ~ |
| Frequency | 50 | Hz |
| Optional frequency | 60 | Hz |
| Power | 41 | W |
| Current | 0.18 | A |
| Speed | 2040 | r.p.m. |
| Max. temperature of transported air | 80 | °C |
| Max. temperature of transported air when speed controlled | 80 | °C |
| Sound pressure level at 3 m | 37 | dB(A) |
| Weight | 2.5 | kg |
| Enclosure class | 44 | IP |
| Insulation class, motor | F | |
| Capacitor | 3 | µF |
| Duct connection | 100 | mm |
| Max. flow @ 0Pa | 62 | l/s |
| Max. pressure | 319 | Pa |
| Voltage range | 220-240 | V |
